MAGNETIC BROOM – SWEEPER FOR CLEANING CARRIERS

Magnetic broom (magnetic sweeper) MM 800 F for cleaning carriers This magnetic broom serves to the collection of metal impurities (metal shavings, nails, grinding dust), mostly in extensive areas (e.g. production halls). It can be easily installed onto the cleaning carrier (into its front or rear part) or, possibly, onto forklift trucks.   How the broom can […]

More detailed information

Magnetic broom (magnetic sweeper) MM 800 F for cleaning carriers

This magnetic broom serves to the collection of metal impurities (metal shavings, nails, grinding dust), mostly in extensive areas (e.g. production halls). It can be easily installed onto the cleaning carrier (into its front or rear part) or, possibly, onto forklift trucks.



How the broom can be cleaned?

Demagnetize the broom by lifting both of the levers; caught metal particles fall off easily.



Magnetic broom (magnetic sweeper) benefits

      • Easy handling
      • Easy cleaning – lever mechanism
      • Variable magnetic area width
      • Stainless steel design
      • High resistance



Miscellaneous metal waste – collection tests

MM 800 F
51712
Distance from the surface
30 mm 50 mm 80 mm
Lifted object Collection success rate
Small office clip (0,3 g) 100 % 100 % 80 %
Steel splinter (1,4 g) 100 % 100 % 0 %
Self-tapping screw 4×60 (2,8 g) 100 % 100 % 70 %
Self-tapping screw 5×80 (6 g) 100 % 100 % 40 %
Pad 5 (0,3 g) 100 % 100 % 0 %
Pad 8 (1,5 g) 100 % 90 % 0 %
Pad 10 (2,9 g) 100 % 90 % 0 %
Nut M5 (1,1 g) 100 % 30 % 0 %
Nut M8 (4,6 g) 100 % 10 % 0 %
Nut M10 (10 g) 100 % 10 % 0 %
Screw M6x10 (4 g) 100 % 10 % 0 %
Screw M8x20 (11,8 g) 100 % 50 % 0 %
Screw M10x55 (37,4 g) 100 % 60 % 0 %
